Specifications:
• Materials
.. Housing: 305 Stainless steel
.. Pin: Inconel X-750
.. Insulation: Glass-ceramic
.. Flange: 304 Stainless steel
.. Magnetic Materials: No
.. Contacts: 300 Series Stn. Stl.
• Voltage Rating 500 V DC
• Current Rating 1 Amp
• Temperature Range
.. -269º C to 350º C, ISO KF -25º C to 205º C
• Pressure @ 20ºC
.. 1400 PSIG (97 Bar), ISO KF 0 PSIG
• Leak Rate <1x10-10 mbar L/s (He)
