RGA Residual Gas Analyzer

Extrel RGA
The lastest Residual Gas Analyzer for your Vacuum System
RGA , Ion Gauge and Pirani Gauge All on a Single Probe





Download Product Information






Specification:

Mass Range:                                   100 or 300 amu systems

Probe Mounting:                              DN 40 CF Flange, Minimum Tube I.D. 35 mm

Resolution:                                      1 amu at 10% Peak Height

General Sensitivity:                         0,15 mA/Torr

Partial Pressure Detectability:         5 x 10 -14 mbar (Channeltron)
                                                        5 x 10 -10 mbar (Faraday)

Total Pressure Gauge Range:        Atmosphere to 10 -9 mbar L/s, Full Range Gauge Pirani/Bayard-Alpert

Mass Position Stability:                  +/- 0,1 amu stability over 24 hours

Electron Energy Range:                 10 to 150 eV

Max. Operating Pressure
with filament on:                              10 -4 mbar

Bakeout Temperature                     100°C with electronics connected
                                                        350°C with electronics not connected

Power:                                             120/230VAC, 50/60 Hz

Weight:                                            2,25 kg


Features:


• Full Range Gauge reading


• Partial pressure reading in Torr

• Compact Size, Long probe (172,5 mm)

• RGA Windows XP Software

• Plug & Play , Easy to use
