Feedthr I/P KF16 2Pin AMPS05 Nickel

Extra information

Specifications
Materials
Housing: 304 Stainless steel
Pin: See table
Insulation: Alumina ceramic
Flange: 304 Stainless steel
Magnetic Materials: See table
Voltage Rating See table
Current Rating See table
Temperature Range
-269º C to 450º C, ISO KF -25º C to 205º C
Pressure @ 20ºC
2 & 4 pin: 1400 PSIG (96 Bar), 8 pin: 500 PSIG (34 Bar)
Leak Rate <1x10-10 mbar L/s (He)
