/ Electrical Feedthroughs / Coaxial / SMA / Coaxial, SMA, 50 OHM High Frequency, Double Ended, 45 GHz, Conflat Flange
Coaxial 3x SMA 50Ohm HF 45GHz, CF35

Coaxial 3x SMA 50Ohm HF 45GHz, CF35

Item number: 23762-01-CF
In stock: No
Description:Coaxial 3x SMA 50Ohm HF 45GHz, CF35

Extra information

Coaxial - SMA 50 Ohm High Frequency/Double Ended
• Installation: Weld, • No. Pins: 1 Female 2.92mm SMA JACK both ends
• Assembly to be leak tight to 1x10E-9 ATM cc/sec Helium
• Assembly can operate at frequencies up to 45 GHz
• Temperature range: -200°C to 250°C
• Nominal impedance: 50 Ohms
• Assembly is both Laser or TIG weldable

CodeFlangePinsFrequency GHzPrice ex.Qty
23762-01-CFNW35CF345
On request
 ×1
= in stock. = out of stock.
